  • S500WG Turbocharger used For D12 Ship with D12M Engine Turbo 56509880000 56501970000 3886223 3801134

S500WG Turbocharger used For D12 Ship with D12M Engine Turbo 56509880000 56501970000 3886223 3801134

Product description:

Turbo Model : S500WG

Fuel : Diesel

Part Number : 56509880000

Brand Name : Booshiwheel

Displacement : 12.14L, 1214 ccm

KW : 578/786

RPM Max : 2300

OE number : 3886223 3801134

Applications : Volvo D12 Ship

标签 : Turbocharger

Welcome to contact us :



Name: Cindy Yang

QQ: 3472219925

Wechat: + 86 18912392873

Whatsapp: + 86 17351503656

E-mail: Sales03@booshiwheel.com

Products description



Part Number 56509880000
Previous Part Number 5650-988-0000, 56501970000
OE number 3886223, 3801134
Year 2006-08
Description Ship, Marine
Manufacturer Part Number 5650-197-0000, 56501970000
CHRA  NEW IN STOCK
Turbo Model S500WG-110_55AABM/0.70HJ3
Engine Model D12M, D12C-A MP, D12D-A MP, D12D-B MP, D12D-C MP
Engine Manufacturer Volvo
Displacement 12.14L, 1214 ccm
KW 578/786
RPM Max 2300
Fuel Diesel
Equip. 452164-5001S
Angle α (compressor housing) 108°
Angle β (turbine housing) 320°
Bearing Housing 317303 (Oil Cooled)
Turbine Wheel 318156 (Ind. 88.95 mm, Exd. 99. mm, 11 Blades)  NEW IN STOCK
Comp. Wheel 317294 (Ind. 78.32 mm, Exd. 114.57 mm, Trm 8.99, 8+8 Blades, Billet) NEW IN STOCK
Back plate 317311 (171524) NEW IN STOCK
Heat shield Number 318032
Repair Kit 318416 NEW IN STOCK
Turbine Housing water-cooled
Settings for waste gate Pressure: 2.05 kPa Stroke: 4.0 mm
Turbo Mnt. Gasket 20784537
Gasket (turbine inlet) 470939 (417382, 20784537) (Stainless Steel)
Gasket oil inlet 420641 (1006177)
Gasket (oil outlet) 470993 (1027702)
NOTE Inter-cooler
