GT1749V 713672-0005 038253019C Turbo charger For Skoda

Product description:

Turbo Model : 713672-5006

Fuel : Diesel

Part Number : 713672-5006S 713672-0006 713672-5006

Brand Name : Booshiwheel

Displacement : 1.9L, 1896 ccm, 4CYL

OE number : 038253019C, 038253019CV500, 03G253016N, 038253019CV225

Year : 00-06

product describtion

Part Number	713672-5006S
Previous Version	713672-0002, 713672-0003, 713672-0004, 713672-0005, 713672-5005S
OE number	038253019C, 038253019CV500, 03G253016N, 038253019CV225
Year	00-06
Description	Audi A3, Seat Leon, Volkswagen Beetle, Golf IV
CHRA	433395-0020 (433395-0040)
Turbo Model	GT1749V(S1)
Engine	PD UI, ALH, AHF, AJM, AUY
Engine Manufacturer	VW
Displacement	1.9L, 1896 ccm, 4CYL
KW	81/85
RPM Max	4000
Angle α (compressor housing)	177
Angle β (turbine housing)	90
Bearing Housing	433145-0005/722282-0002
Turbine Wheel	434533-0002/434533-0039
Comp. Wheel	434812-0001/434812-0002
Back plate	700593-0006
Heat Shield	433112-0001
Thrust Kit	732248-0003/732252-0001
Service Kit, Major	732248-003/732245-0001
Turbine Housing AR	VNT1
Actuator	434855-0015
Settings Waste gate adjustment (pressure)	0.224-0.229 bar
Settings Waste gate (lift shaft)	0.5-4.0 mm
Gasket exhaust manifold	210664
Gasket (turbine outlet)	210311
Gasket (oil outlet)	210243
Gasket actuator EGR	210313
