Product description:
Turbo Model : 54359880005 54359700005
Fuel : Diesel
Part Number : 54359880005 54359700005
Brand Name : Booshiwheel
Displacement : 1.25L, 1248 ccm
KW : 51/55
OE number : 73501343 71784113 93191993
Year : 2003
Applications : 2003- Fiat Doblo 1.3 JTD Engine 16V Multijet 2003- Fiat Idea 1.3 JTD Engine 16V Multijet
product describtion
| Part Number | 54359880005 |
| OE number | 73501343, 71784113, 5860030, 93191993 |
| Description | Commercial, Cars |
| Manufacturer Part Number | 54359700005 |
| CHRA | 54357100503 |
| Turbo Model | KP35-1570CBC180.85ACAXD |
| Engine | SJTD, 16V Multijet, Z13DTJ |
| Application | POINT-Panda-MUSA-FIORINO, Opel Corsa, Lancia |
| Displacement | 1.25L, 1248 ccm |
| KW | 51/55 |
| RPM Max | 4500 |
| Fuel | Diesel |
| Angle α (compressor housing) | 143 |
| Angle β (turbine housing) | 189 |
| Bearing Housing | 54351523003 |
| Heat Shield | 54351652000 |
| Turbine Housing | 54351009017 |
| Compressor Cover | 54351014808 |
| Turbine Housing AR | 180 |
| Actuator | 58201104311/58201104216 |
| settings Wastegate (pressure) | 1,38 bar |
| settings Wastegate (lift shaft) | 2.00 mm |
| NOTE | Intercooler |
